The Cable Forces and Pulley Blocks Apparatus, manufactured by Atto Labware, is an educational trainer designed to demonstrate the behavior of forces in cables and pulley systems. It helps students study tension, equilibrium, and force distribution in different cable arrangements. This apparatus is ideal for engineering institutes, polytechnics, and vocational training centers to teach applied mechanics and statics principles.

Educational Objectives
Students will be able to:

• Understand the equilibrium of forces in cable and pulley systems.

• Study tension distribution in single and multiple pulleys.

• Analyze the effect of load, angle, and configuration on cable forces.

• Apply vector methods to solve force systems.

• Verify theoretical principles through hands-on experiments.

Performance Measurement

• Demonstration of force equilibrium using cable and pulley systems.

• Measurement of tensions and load distribution.

• Observation of vector diagrams and equilibrium conditions.

• Analysis of different cable configurations under load.

• Validation of theoretical calculations with practical data.

Panel and Instruments / Components

• Rigid base frame with pulley mounting system.

• Multiple pulley blocks with adjustable positions.

• Cables, weight hangers, and calibrated weights.

• Scales and protractors for measurement and angle setting.

• Instructional panel and manuals for guided experiments.

• Safe, durable, and portable construction for laboratory use.

⚡ Manufacturer: Atto Labware
Note: Customized specifications and accessories are available on request.
